CPU |
Intel® Socket 1155 for Intel® 2nd Generation Core™ i7 Processor/Core™ i5 Processor/Core™ i3 Processor/
Support Enhanced Intel SpeedStep Technology (EIST)
Supports Intel® Turbo Boost Technology 2.0
* The Intel® Turbo Boost technology 2.0 support depends on the CPU types
* Refer to www.asus.com for Intel® CPU support list. |
|
Chipset |
Intel® P67 Express Chipset |
|
Memory |
4 x DIMM, Max. 32 GB, DDR3 2200(O.C.)*/2133(O.C.)*/1866(O.C.)/1600(O.C.)/1333/1066 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* According to Intel® SPEC, the Max. 32GB memory capacity can be supported with DIMMs of 8GB (or above). ASUS will update QVL once the DIMMs are available on the market.
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Some hyper DIMMs only support one DIMM per channel. Please refer to Memory QVL for details.
* Due to CPU behavior, DDR3 2200/2000/1800 MHz memory module will run at DDR3 2133/1866/1600 MHz frequency as default. |
|
Expansion Slots |
2 x PCIe 2.0 x16 slots (Single@x16 or dual@x8/x8 mode or dual@x16/x1 mode)
1 x PCIe 2.0 x16 slot (black, max.@x4 mode, compatible with PCIe x 1 and x4 devices)
1 x PCIe 2.0 x1 slot |
|
Storage |
Intel® P67 Express Chipset
4 xSATA 3.0 Gb/s ports (blue)
2 xSATA 6.0 Gb/s ports (gray)
Intel Rapid Storage Technology Support RAID 0,1,5,10
Marvell® PCIe SATA 6Gb/s controller
1 xExternal SATA 6.0 Gb/s port
1 xSATA 6.0 Gb/s port (navy blue) |
|
LAN |
Realtek® RTL8111E Gigabit LAN controller |
|
Audio |
Realtek® ALC892 8-Channel Audio CODEC supports DTS Surround Sensation UltraPC
- Optical S/PDIF Out port at back I/O
- Supports Jack-Detection, Multi-streaming, Front Panel Jack-Retasking(HD only) |
|
IEEE 1394 |
VT6315N controller supports 2 x 1394a port(s) (1 port at mid-board, 1 port at back panel) |
|
USB |
Chipset built-in
- 2 x USB 3.0/2.0 ports (blue, at back panel)
Chipset built-in
- 14 x USB 2.0/1.1 ports (8 ports at mid-board, 6 ports at back panel) |
|
ASUS Unique Features |
- 100% All High-quality Conductive Polymer Capacitors
- TPU
- ASUS Turbo V
- Auto Tuning
- Anti-Surge Protction
- Mem OK!
- ASUS EPU
- CrossFireX Support
- SLI Support
- Protect 3.0
- AI Suite II
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2 |
|
Overclocking Features |
SFS (Stepless Frequency Selection)
- Internal Base Clock tuning from 80MHz up to 300MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall) |
|
Back Panel I/O Ports |
1 x PS/2 Mouse
1 x PS/2 Keyboard
1 x External SATA
1 x IEEE 1394a
1 x LAN(RJ45) port(s)
2 x USB 3.0/2.0
6 x USB 2.0/1.1
1 x S/PDIF Out (Optical)
8 -Channel Audio I/O |
|
Internal I/O Connectors |
4 x USB connectors support additional 8 USB ports
1 x MemOK! Button
1 x TPM connector
3 x SATA 6.0Gb/s connectors
4 x SATA 3.0Gb/s connectors
1 x IEEE 1394a connector
1 x CPU Fan connector(s)
2 x Chassis Fan connector(s)
1 x Power Fan connector(s)
1 x LPT connector
1 x TPU switch
1 x S/PDIF Out connector
1 x 24-pin ATX Power connector
1 x 8-pin ATX 12V Power connector
1 x Front panel audio connector
1 x COM connector
1 x System Panel connector |
|
BIOS |
32 Mb Flash ROM , EFI AMI BIOS, PnP, DMI2.0, WfM2.0, ACPI v2.0a, SM BIOS v2.6, Multi-language BIOS |
|
Accessories |
User's manual
2 x SATA 3.0Gb/s cables
2 x SATA 6.0Gb/s cables
1 x Q-Shield
1 x Q-Connecor (retail version only) |
|
Support Disc |
Drivers
Anti-virus software (OEM version)
ASUS Update
ASUS Utilities
Support DVD |
|
Form Factor |
uATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
