MANHATTAN Scanner, CCD, 1D, USB
Du måste logga in för att kunna handla/se priser.
|
|
MANHATTAN Scanner, CCD, 1D, USB
|
Beskrivning
Specifikationer
Long Range CCD Barcode Scanner
Improve speed, accuracy and productivity
MANHATTAN Long Range CCD Barcode Scanner delivers basic, high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The scan engine features no moving parts for years of reliable service reading popular 1D barcodes including UPC, EAN, ASCII, MSI/PLESSEY, GS1 DataBar and more. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application where it appears as if it was manually typed or directly keyed into the computer. Its versatile switchable USB or PS/2 cable interface integrates with most PCs without an external power supply. With a scan rate of 100 scans per second and an accurate read range of up to 200 mm (7.8 in.), this model offers an effective and efficient, all-purpose daily scanning solution for less demanding point-of-sale, office and other low ambient light applications to minimize manual data entry, speed transactions and reduce errors.
- Helps speed data entry, reduce errors and improve efficiency – ideal for retail transactions and automated processes
- Keyboard Wedge Decoder displays data as if directly entered from keyboard
- Wide scan field provides quick, accurate reads with up to 100 scans per second up to 200 mm (8 in.) away
- Detects many popular symbologies including UPC, EAN and GS1 DataBar
- Switchable interface integrates with most PCs
- Easy to install and use without software or special training
- Lifetime Warranty
General
- Supports character editing and ISP function
- Light source: red LED
- Scanner width: 60 mm
- Width of field: 100 mm
- View angle: 35°
- Scanner range: 200 mm @ 20 mil/0.5 mm, PCS 90%
- Resolution: 0.127 mm (5 mil) @ PCS 0.9
- Reading indicator: tone and LED
- Ambient light: 5,000 lux maximum
- Scan rate: 100 scans/second
- Interface: USB
- Switch: button
Physical
- Dimensions: 14 x 7 x 9 cm (5.5 x 2.75 x 5.5 in.)
- Weight: 115 g (4 oz.)
- Cable length: 1.5 m (5 ft.)
- Operating temperature: 0 – 50°C
- Storage temperature: -20 – 70°C
- Relative humidity: 20 ± 95% (non-condensing)
- Housing: ABS and rubber
| Modell | Handhållen steckkodsläsare |
| Skanningstyp | 1D |
| Bildsensortyp | CCD |
| 1D -streckkoder (linjära) som stöds | Codabar, Code 11, Code 128, Code 39, Code 93, Industrial 2 of 5, Interleaved 2 of 5, JAN, MSI, Plessey, Telepen |
| 2D-streckkoder (matriser och staplade) som stöds | Stöds inte |
| Arbetsavstånd | 50 cm |
| Läs hastighet (max) | 500 läsningar/s |
| Ljusnivåer (direkt solljus) | 0 - 10000 lx |
| Maximal skanningsstorlek bredd | 10 cm |
| Anslutningsteknologi | Kabel |
| Standardgränssnitt | USB |
| Kabellängd | 1,5 m |
| Produktens färg | Svart |
| Material, hölje | Akrylnitrilbutadienstyren (ABS), Gummi |
| Certifiering | FCC, CE, USB |
| Strömkälla av typen | USB |
| Spänning | 5 V |
| Strömförbrukning | 150 mA |
| Bredd | 89 mm |
| Djup | 177,5 mm |
| Höjd | 19 mm |
| Vikt | 440 g |
| Temperatur vid drift | 0 - 50 ° C |
| Temperaturintervall (förvaring) | -20 - 70 ° C |
| Intervall för relativ operativ luftfuktighet | 20 - 95% |
| Certifikat för överensstämmelse | CE, Federal Communications Commission (FCC) |
| Harmonized System (HS)-kod | 84716070 |
Även om vi gör vårt bästa för att ge relevant information, så är bilderna bara till för att ge ett generellt intryck, och själva varan behöver nödvändigtvis inte se ut precis som på bilden. Om det är skillnader mellan produktöverskrift, beskrivning och bild, så är det produktöverskriften som gäller. (tex. Pc:n kommer inte nödvändigtvis med monitor även om bilden visar det) Om något är oklart skicka en e-post till oss före du beställer! Vi förbehåller oss för tryckfel, ändringar av priser och specifikationer utan varsel.
