EPSON DFX-9000N/EN Dot 560cps A4 ENet

Du måste logga in för att kunna handla/se priser.
EPSON DFX-9000N/ EN Dot 560cps A4 ENet (C11C605011A3)
EPSON DFX-9000N/ EN Dot 560cps A4 ENet (C11C605011A3)
EPSON DFX-9000N/ EN Dot 560cps A4 ENet (C11C605011A3)
EPSON DFX-9000N/ EN Dot 560cps A4 ENet (C11C605011A3)
EPSON DFX-9000N/ EN Dot 560cps A4 ENet (C11C605011A3)
EPSON DFX-9000N/ EN Dot 560cps A4 ENet (C11C605011A3)

EPSON DFX-9000N/EN Dot 560cps A4 ENet

Artikelnr:
C11C605011A3
EAN:
8715946415123
  • Typ 9-pin Dot matrix
Lager i butik Inte i lager Hos leverantör Förväntad i lager 2026-05-05
Kontakta mig när varan finns i lager
Beskrivning
Specifikationer
Relaterade produkter


Epson DFX-9000
The DFX-9000, a heavy duty printer you can rely on
The Epson DFX-9000 is a fast 9-pin heavy duty dot matrix printer. Built to bring your business speed and reliability, it gives you the power to handle the most demanding workloads quickly and at exceptional value

Working at high speeds
With a 1,550cps print speed, the Epson DFX-9000 delivers exceptional performance in all data processing and drafting tasks.

Working reliably
You can rely on the ongoing support of a print volume of 133 million lines MVBF (mean volume between failure), an MTBF (mean time between failure) of 20,000 power on hours and a 15 million characters ribbon life. Durability that keeps your business working

Working in any environment
You can integrate the Epson DFX-9000 with existing equipment, using standard USB, Parallel and Serial interfaces (optional network, twinax, coax).

Working for your business
Utilise extensive paper handling solutions to deal with a wide range of commercial, industrial and logistic printing tasks.
Print up to 10 part forms on paper from 76.2 to 406.4mm wide. And extend your printing capabilities with the optional perforation cutter.

DFX-9000N
Also available as network version with network interface card included in the box. Order Code: C11C605011A3 (220V) and C11C605011A5 (240V). For pricing and more information, please contact our local representatives.



Printer Type


Product name



Epson DFX-9000

Product code



C11C605

Number of pins



4 groups of 9

Print direction



Bi-direction with logic seeking

Printing method



Impact dot matrix

Numbers of columns



136 columns (10cpi), 163 columns (12cpi), 204 columns (15cpi), 233 columns (17cpi), 272 columns (20cpi)




Print Speed


High speed draft 10CPI



1550cps

High speed draft 12CPI



1450cps

Draft 10CPI



1320cps

Draft 12CPI



1320cps

LQ 10CPI



330cps

LQ 12CPI



330cps




Print Characteristics


Bitmap fonts



Yes

Barcode fonts



EAN-13

EAN-8

Interleaved 2 of 5

UPC-A

Code 39

Code 128

POSTNET




Paper Handling


Paper path



Tractor (Front or rear in, top out)

Cut sheet size



W x L = 76.2 x 76.2mm to 419.1 x 558.8mm

Thickness: Min. 0.065mm, max. 0.10mm

Weight: Min. 52 g/m2, max. 82 g/m2

Multi-part forms



Copies: 1 original + 6 copies (Rear entry), 1 original + 9 copies (Front entry)

Paper feeding



Push tractor feed (front, rear), Push & Pull Tractor feed (front, rear)




Acoustic Noise Level


Acoustic noise level



58 dB(A)




Input Data Buffer


Input data buffer



128KB




Interface


Standard



Bi-directional parallel interface (IEEE 1284 nibble mode supported), Serial, USB (version1.1)

Option



Type B level 2




Ribbon Cartridge


Colour



Black

Type



Fabric

Ribbon life



15 million characters (Draft 10cpi, 14 dots/character)




Reliability


MTBF



20,000

Print head life



400,000 million characters




Electrical Specifications


Rated voltage



AC 100 to 240 V

Rated frequency



50 to 60HzApprox. 185W.

Power consumption



Approx. 7.5W in sleep mode

Energy Star



Compliant




Dimensions


Width



700 mm

Depth



378 mm

Height



363 mm

Weight



34 kg




Warranty


Standard



1 year on site

Optional



Epson CoverPlus 3 years extended warranty on site ECPGRP070




Options


Options



Ribbon Cartridge (Black) (S015384)

Perforation Cutter (C12C815072)

Pull Tractor Unit (C12C800382)

100 BaseTx/10BaseT Ethernet Print Server (C12C823914)

32KB intelligent serial I/F card (C12C823081)

Serial I/F card (C12C823061)

32KB IEEE-488 I/F card (C12C823132)

IEEE-1284 parallel I/F card (C12C823453)

Coax I/F card (C12C823142)

Twinax I/F card (C12C823152)

Local Talk I/F card (C12C823122)
